Product CatalogPart Number
DO3316P-683MLD
Manufacturer
CoilcraftDescription
FIXED IND 68UH 1.5A 200MOHM SM
Datasheet
DatasheetPackage
Nonstandard
In Stock
54,194 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
DO3316P-683MLD
DO3316P-683MLD
lmages are for reference only.Payment Methods
Delivery Services
68 µH Unshielded Drum Core Inductor 1.5 A 200mOhm Max Nonstandard
Quick Inquiry
DO3316P-683MLD
Specifications
| Category | Inductors, Coils, Chokes - Fixed Inductors - |
| Manufacturer | Coilcraft |
| Series | DO3316 |
| Packaging | Tape & Reel (TR) |
| RoHS Status | |
| Type | Drum Core |
| Material - Core | Ferrite |
| Inductance | 68 µH |
| Tolerance | ±20% |
| Current Rating (Amps) | 1.5 A |
| Current - Saturation (Isat) | 1.4A |
| Shielding | Unshielded |
| DC Resistance (DCR) | 200mOhm Max |
| Q @ Freq | - |
| Frequency - Self Resonant | 10MHz |
| Ratings | - |
| Operating Temperature | -40°C ~ 85°C |
| Inductance Frequency - Test | 100 kHz |
| Features | - |
| Mounting Type | Surface Mount |
| Package / Case | Nonstandard |
| Supplier Device Package | - |
| Size / Dimension | 0.510" L x 0.370" W (12.95mm x 9.40mm) |
| Height - Seated (Max) | 0.205" (5.21mm) |
| Base Product Number | - |
Parts with Similar Specifications
| Product Attribute |  |
 |
 |
 |
| Part Number | DO3316P-102MLD | DO3316P-103MLD | DO3316P-104MLD | DO3316P-105MLD |
| Manufacturer | Coilcraft | Coilcraft | Coilcraft | Coilcraft |
| RoHS Status | ||||
| Description | FIXED IND 1UH 6.8A 9MOHM SM | FIXED IND 10UH 3.9A 38MOHM SM | FIXED IND 100UH 1.3A 280MOHM SM | FIXED IND 1MH 300MA 3OHM SM |
| Series | Coilcraft | Coilcraft | Coilcraft | Coilcraft |
| Packaging | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) |
