XTAL OSC OCXO 24.0000MHZ LVCMOS
Datasheet6-SMD, No Lead
93,299 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
24 MHz OCXO LVCMOS Oscillator 3.3V 6-SMD, No Lead
DOCSC022F-024.0M
| Category | Crystals, Oscillators, Resonators - Oscillators - |
| Manufacturer | Connor Winfield |
| Series | DOCSC |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Base Resonator | Crystal |
| Type | OCXO |
| Frequency | 24 MHz |
| Function | - |
| Output | LVCMOS |
| Voltage - Supply | 3.3V |
| Frequency Stability | ±20ppb |
| Absolute Pull Range (APR) | - |
| Operating Temperature | -40°C ~ 85°C |
| Spread Spectrum Bandwidth | - |
| Current - Supply (Max) | - |
| Ratings | - |
| Mounting Type | Surface Mount |
| Package / Case | 6-SMD, No Lead |
| Size / Dimension | 0.555" L x 0.358" W (14.10mm x 9.10mm) |
| Height - Seated (Max) | 0.335" (8.51mm) |
| Base Product Number | - |
| Product Attribute |  |
|
 |
 |
| Part Number | DOCSC022F-024.576M | DOCSC022F-020.0M | DOCSC022F-025.0M | DOCSC022F-026.0M |
| Manufacturer | Connor Winfield | Connor Winfield | Connor Winfield | Connor Winfield |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | XTAL OSC OCXO 24.5760MHZ LVCMOS | XTAL OSC OCXO 20.0000MHZ LVCMOS | XTAL OSC OCXO 25.0000MHZ LVCMOS | XTAL OSC OCXO 26.0MHZ 3.3V SMD |
| Series | Connor Winfield | Connor Winfield | Connor Winfield | Connor Winfield |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
