DRV8143HQDGQRQ1
lmages are for reference only.DRV8143HQDGQRQ1
AUTOMOTIVE 40-V, 20-A HALF-BRIDG
Datasheet28-PowerTSSOP (0.118", 3.00mm Width)
70,841 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Bipolar Motor Driver Bi-CMOS Hardwired (HW) 28-HTSSOP
DRV8143HQDGQRQ1
| Category | Integrated Circuits (ICs) - Power Management PMIC - Motor Drivers-Controllers |
| Manufacturer | Texas Instruments |
| Series | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Motor Type - Stepper | Bipolar |
| Motor Type - AC, DC | Brushed DC |
| Function | Driver - Fully Integrated, Control and Power Stage |
| Output Configuration | Half Bridge |
| Interface | Hardwired (HW) |
| Technology | Bi-CMOS |
| Step Resolution | - |
| Applications | Automotive |
| Current - Output | 20A |
| Voltage - Supply | 4.5V ~ 35V |
| Voltage - Load | 4.5V ~ 35V |
| Operating Temperature | -40°C ~ 125°C (TA) |
| Mounting Type | Surface Mount |
| Package / Case | 28-PowerTSSOP (0.118", 3.00mm Width) |
| Supplier Device Package | 28-HTSSOP |
| Base Product Number | - |
| Grade | Automotive |
| Qualification | AEC-Q100 |
| Product Attribute | |
 |
|
 |
| Part Number | DRV8143HQDGQRQ1 | DRV8143HQRXYRQ1 | DRV8143HQRXYRQ1 | DRV8143PQDGQRQ1 |
| Manufacturer | Texas Instruments | Texas Instruments | Texas Instruments | Texas Instruments |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | AUTOMOTIVE 40-V, 20-A HALF-BRIDG | AUTOMOTIVE 40-V, 20-A HALF-BRIDG | AUTOMOTIVE 40-V, 20-A HALF-BRIDG | AUTOMOTIVE 40-V, 20-A HALF-BRIDG |
| Series | - | - | - | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
