Buffer, ReDriver 2 Channel 10.3Gbps 24-WQFN (4x4)
DS100BR111ASQE/NOPB
| Category | Integrated Circuits (ICs) - Interface - Signal Buffers-Repeaters-Splitters |
| Manufacturer | Texas Instruments |
| Series | - |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| Type | Buffer, ReDriver |
| Applications | SATA |
| Input | CML |
| Output | CML |
| Data Rate (Max) | 10.3Gbps |
| Number of Channels | 2 |
| Delay Time | - |
| Signal Conditioning | Input Equalization, Output De-Emphasis |
| Voltage - Supply | 2.375V ~ 3.6V |
| Current - Supply | 50mA |
| Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Surface Mount |
| Package / Case | 24-WFQFN Exposed Pad |
| Supplier Device Package | 24-WQFN (4x4) |
| Base Product Number | DS100BR111 |
| Capacitance - Input | 10 pF |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | DS100BR111ASQ/NOPB | DS100BR111SQ/NOPB | DS100BR111SQE/NOPB | DS100BR210SQ/NOPB |
| Manufacturer | Texas Instruments | Texas Instruments | Texas Instruments | Texas Instruments |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | IC REDRIVER SATA 2CH 24WQFN | IC REDRIVER SATA 2CH 24WQFN | IC REDRIVER SATA 2CH 24WQFN | IC REDRIVER SATA 2CH 24WQFN |
| Series | - | - | - | - |
| Packaging | Tape & Reel (TR) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
