DS1302+
lmages are for reference only.DS1302+
IC RTC CLK/CALENDAR SER 8DIP
Datasheet8-DIP (0.300", 7.62mm)
26,618 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Real Time Clock (RTC) IC Clock/Calendar 31B 3-Wire Serial 8-DIP (0.300", 7.62mm)
DS1302+
| Category | Integrated Circuits (ICs) - Clock-Timing - Real Time Clocks |
| Manufacturer | Analog Devices Inc./Maxim Integrated |
| Series | - |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| Type | Clock/Calendar |
| Features | Leap Year, NVSRAM, Trickle-Charger |
| Memory Size | 31B |
| Time Format | HH:MM:SS (12/24 hr) |
| Date Format | YY-MM-DD-dd |
| Interface | 3-Wire Serial |
| Voltage - Supply | 2V ~ 5.5V |
| Voltage - Supply, Battery | 2V ~ 5.5V |
| Current - Timekeeping (Max) | 0.3µA ~ 1µA @ 2V ~ 5V |
| Operating Temperature | 0°C ~ 70°C |
| Mounting Type | Through Hole |
| Package / Case | 8-DIP (0.300", 7.62mm) |
| Supplier Device Package | 8-PDIP |
| Base Product Number | DS1302 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | DS1302 | DS1302N | DS1302N+ | DS1302S |
| Manufacturer | Analog Devices Inc./Maxim Integrated | Analog Devices Inc./Maxim Integrated | Analog Devices Inc./Maxim Integrated | Analog Devices Inc./Maxim Integrated |
| RoHS Status | RoHS non-compliant | RoHS non-compliant | ROHS3 Compliant | RoHS non-compliant |
| Description | IC RTC CLK/CALENDAR SER 8DIP | IC RTC CLK/CALENDAR SER 8DIP | IC RTC CLK/CALENDAR SER 8DIP | IC RTC CLK/CALENDAR SER 8SOIC |
| Series | - | - | - | - |
| Packaging | Tube | Tube | Tube | Tube |
