DSA1001DL2-008.0000TVAO
lmages are for reference only.DSA1001DL2-008.0000TVAO
MEMS OSCILLATOR, AUTOMOTIVE, CMO
Datasheet4-VDFN
27,533 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
8 MHz XO (Standard) CMOS Oscillator 1.7V ~ 3.6V Standby (Power Down) 4-VDFN
DSA1001DL2-008.0000TVAO
| Category | Crystals, Oscillators, Resonators - Oscillators - |
| Manufacturer | Microchip Technology |
| Series | DSA1001 |
| Packaging | Bulk |
| RoHS Status | ROHS3 Compliant |
| Base Resonator | MEMS |
| Type | XO (Standard) |
| Frequency | 8 MHz |
| Function | Standby (Power Down) |
| Output | CMOS |
| Voltage - Supply | 1.7V ~ 3.6V |
| Frequency Stability | ±25ppm |
| Absolute Pull Range (APR) | - |
| Operating Temperature | -40°C ~ 105°C |
| Spread Spectrum Bandwidth | - |
| Current - Supply (Max) | 8mA |
| Ratings | AEC-Q100 |
| Mounting Type | Surface Mount |
| Package / Case | 4-VDFN |
| Size / Dimension | 0.098" L x 0.079" W (2.50mm x 2.00mm) |
| Height - Seated (Max) | 0.035" (0.90mm) |
| Base Product Number | DSA1001 |
| Product Attribute |  |
|
|
|
| Part Number | DSA1001DL2-001.5625TVAO | DSA1001DL2-001.5625VAO | DSA1001DL2-004.0000TVAO | DSA1001DL2-004.0000VAO |
| Manufacturer | Microchip Technology | Microchip Technology | Microchip Technology | Microchip Technology |
| RoHS Status | ||||
| Description | MEMS OSC., AUTOMOTIVE, LOW POWER | MEMS OSC., AUTOMOTIVE, LOW POWER | MEMS OSC, AUTO, LVCMOS, 4MHZ, 25 | MEMS OSC, AUTO, LVCMOS, 4MHZ, 25 |
| Series | Microchip Technology | Microchip Technology | Microchip Technology | Microchip Technology |
| Packaging | Tape & Reel (TR) | Tube | Tape & Reel (TR) | Tube |
