E36D800HPN822MA79U
lmages are for reference only.Payment Methods
Delivery Services
8.2 mF 80 V Aluminum Electrolytic Capacitors Radial, Can - Screw Terminals 21.7mOhm @ 120Hz 2000 Hrs @ 85°C
E36D800HPN822MA79U
| Category | Capacitors - Aluminum Electrolytic Capacitors - |
| Manufacturer | Chemi-Con |
| Series | U36D |
| Packaging | Bulk |
| RoHS Status | |
| Capacitance | 8.2 mF |
| Tolerance | ±20% |
| Voltage - Rated | 80 V |
| ESR (Equivalent Series Resistance) | 21.7mOhm @ 120Hz |
| Lifetime @ Temp. | 2000 Hrs @ 85°C |
| Operating Temperature | -40°C ~ 85°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 5.65 A @ 120 Hz |
| Ripple Current @ High Frequency | 7.91 A @ 3 kHz |
| Lead Spacing | 0.500" (12.70mm) |
| Size / Dimension | 1.378" Dia (35.00mm) |
| Height - Seated (Max) | 3.110" (79.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Chassis Mount |
| Package / Case | Radial, Can - Screw Terminals |
| Base Product Number | - |
| Impedance | - |
| Product Attribute | |
|
 |
|
| Part Number | E36D800HPN822MC54M | E36D800HLN104MEE3M | E36D800HLN104MEE3U | E36D800HLN473ME92M |
| Manufacturer | Chemi-Con | Chemi-Con | Chemi-Con | Chemi-Con |
| RoHS Status | RoHS Compliant | RoHS Compliant | ROHS3 Compliant | RoHS Compliant |
| Description | CAP ALUM 8200UF 20% 80V SCREW CH | CAP ALUM 100000UF 20% 80V SCREW | CAP ALUM 100000UF 20% 80V SCREW | CAP ALUM 47000UF 20% 80V SCREW |
| Series | Chemi-Con | Chemi-Con | Chemi-Con | Chemi-Con |
| Packaging | Bulk | Bulk | Bulk | Bulk |
