E3M0021120J2-TR
lmages are for reference only.E3M0021120J2-TR
21m, 1200V SiC FET, TO-263-7 XL
DatasheetTO-263-8, D2PAK (7 Leads + Tab), TO-263CA
82,172 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
N-Channel 1200 V 114A (Tc) 500W (Tc) Surface Mount TO-263-7
E3M0021120J2-TR
| Category | Discrete Semiconductor Products - Transistors - FETs-MOSFETs |
| Manufacturer | Wolfspeed, Inc. |
| Series | E |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| FET Type | N-Channel |
| Technology | SiCFET (Silicon Carbide) |
| Drain to Source Voltage (Vdss) | 1200 V |
| Current - Continuous Drain (Id) @ 25°C | 114A (Tc) |
| Drive Voltage (Max Rds On, Min Rds On) | 15V |
| Rds On (Max) @ Id, Vgs | 29mOhm @ 62.12A, 15V |
| Vgs(th) (Max) @ Id | 3.8V @ 17.1mA |
| Vgs (Max) | +19V, -8V |
| Input Capacitance (Ciss) (Max) @ Vds | 5100 pF @ 1000 V |
| FET Feature | - |
| Power Dissipation (Max) | 500W (Tc) |
| Operating Temperature | -55°C ~ 175°C (TJ) |
| Mounting Type | Surface Mount |
| Supplier Device Package | TO-263-7 |
| Package / Case | TO-263-8, D2PAK (7 Leads + Tab), TO-263CA |
| Base Product Number | - |
| Gate Charge (Qg) (Max) @ Vgs | 169 nC @ 15 V |
| Grade | Automotive |
| Qualification | AEC-Q101 |
| Product Attribute | |
|
 |
 |
| Part Number | E3M0021120K | E3M0016120K | E3M0032120J2-TR | E3M0032120K |
| Manufacturer | Wolfspeed, Inc. | Wolfspeed, Inc. | Wolfspeed, Inc. | Wolfspeed, Inc. |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | SIC, MOSFET, 21M, 1200V, TO-247- | SIC, MOSFET, 16M, 1200V, TO-247- | 32m, 1200V SiC FET, TO-263-7 XL | SIC, MOSFET, 32M, 1200V, TO-247- |
| Series | E | - | E | E |
| Packaging | Tube | Tube | Tape & Reel (TR)-->Cut Tape (CT) | Tube |
