ECS-P143-AX
lmages are for reference only.Payment Methods
Delivery Services
XO (Standard) HCMOS 1 MHz ~ 125 MHz Programmable Oscillator 3.3V Enable/Disable 14-DIP, 4 Leads (Full Size, Metal Can)
ECS-P143-AX
| Category | Crystals, Oscillators, Resonators - Programmable Oscillators - |
| Manufacturer | ECS Inc. |
| Series | ECS-P143X |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| Base Resonator | Crystal |
| Type | XO (Standard) |
| Available Frequency Range | 1 MHz ~ 125 MHz |
| Function | Enable/Disable |
| Output | HCMOS |
| Voltage - Supply | 3.3V |
| Frequency Stability | - |
| Frequency Stability (Total) | ±100ppm |
| Operating Temperature | 0°C ~ 70°C |
| Spread Spectrum Bandwidth | - |
| Current - Supply (Max) | 28mA |
| Ratings | - |
| Mounting Type | Through Hole |
| Package / Case | 14-DIP, 4 Leads (Full Size, Metal Can) |
| Size / Dimension | 0.815" L x 0.508" W (20.70mm x 12.90mm) |
| Height - Seated (Max) | 0.197" (5.00mm) |
| Base Product Number | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | ECS-P143-A | ECS-P143-AN | ECS-P143-ANX | ECS-P143-B |
| Manufacturer | ECS Inc. | ECS Inc. | ECS Inc. | ECS Inc. |
| RoHS Status | RoHS non-compliant | RoHS non-compliant | ROHS3 Compliant | RoHS non-compliant |
| Description | XTAL OSC PROG XO HCMOS 3.3V | XTAL OSC PROG XO HCMOS 3.3V | XTAL OSC PROG XO HCMOS 3.3V | XTAL OSC PRG XO HCMOS 3.3V 50PPM |
| Series | ECS-P143 | ECS-P143 | ECS-P143X | ECS-P143 |
| Packaging | Tube | Tube | Tube | Tube |
