Product CatalogPart Number
EGUARD0524P
Manufacturer
SMC Diode SolutionsDescription
TVS DIODE 5VWM 17VC 10DFNWB
Datasheet
DatasheetPackage
10-UFDFN
In Stock
38,380 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
EGUARD0524P
EGUARD0524P
lmages are for reference only.Payment Methods
Delivery Services
17V Clamp 7A (8/20µs) Ipp Tvs Diode Surface Mount 10-DFNWB (2.5x1)
Quick Inquiry
EGUARD0524P
Specifications
| Category | Circuit Protection - Transient Voltage Suppressors TVS - TVS Diodes |
| Manufacturer | SMC Diode Solutions |
| Series | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Type | Steering (Rail to Rail) |
| Bidirectional Channels | - |
| Voltage - Reverse Standoff (Typ) | 5V (Max) |
| Voltage - Breakdown (Min) | 6V |
| Voltage - Clamping (Max) @ Ipp | 17V |
| Current - Peak Pulse (10/1000µs) | 7A (8/20µs) |
| Power - Peak Pulse | 150W |
| Power Line Protection | No |
| Applications | HDMI |
| Capacitance @ Frequency | 0.65pF @ 1MHz |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | 10-UFDFN |
| Supplier Device Package | 10-DFNWB (2.5x1) |
| Base Product Number | EGUARD0524 |
| Unidirectional Channels | 4 |
| Grade | - |
| Qualification | - |
