Product CatalogPart Number
EH24-1.5-02-4M5
Manufacturer
Schaffner EMC Inc.Description
CMC 4.5MH 1.5A 2LN TH
Datasheet
DatasheetPackage
Horizontal, 4 PC Pin
In Stock
85,637 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
EH24-1.5-02-4M5
EH24-1.5-02-4M5
lmages are for reference only.Payment Methods
Delivery Services
4.5 mH @ 400 Hz 2 Line Common Mode Choke Through Hole 1.5A DCR 116mOhm (Typ)
Quick Inquiry
EH24-1.5-02-4M5
Specifications
| Category | Filters - Common Mode Chokes - |
| Manufacturer | Schaffner EMC Inc. |
| Series | EH |
| Packaging | Tray |
| RoHS Status | ROHS3 Compliant |
| Filter Type | Power Line |
| Number of Lines | 2 |
| Inductance @ Frequency | 4.5 mH @ 400 Hz |
| Current Rating (Max) | 1.5A |
| DC Resistance (DCR) (Max) | 116mOhm (Typ) |
| Voltage Rating - DC | - |
| Voltage Rating - AC | 250V |
| Operating Temperature | -25°C ~ 100°C |
| Ratings | - |
| Approval Agency | - |
| Features | - |
| Mounting Type | Through Hole |
| Size / Dimension | 0.945" L x 0.945" W (24.00mm x 24.00mm) |
| Height (Max) | 0.827" (21.00mm) |
| Package / Case | Horizontal, 4 PC Pin |
| Base Product Number | EH24-1 |
| Impedance @ Frequency | - |
| Grade | - |
| Qualification | - |
