Product CatalogPart Number
EPC2306ENGRT
Manufacturer
EPCDescription
TRANS GAN 100V .0038OHM3X5MM QFN
Datasheet
DatasheetPackage
7-PowerWQFN
In Stock
66,530 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
EPC2306ENGRT
EPC2306ENGRT
lmages are for reference only.Payment Methods
Delivery Services
N-Channel 100 V 48A (Ta) Surface Mount 7-QFN (3x5)
Quick Inquiry
EPC2306ENGRT
Specifications
| Category | Discrete Semiconductor Products - Transistors - FETs-MOSFETs |
| Manufacturer | EPC |
| Series | eGaN® |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| FET Type | N-Channel |
| Technology | GaNFET (Gallium Nitride) |
| Drain to Source Voltage (Vdss) | 100 V |
| Current - Continuous Drain (Id) @ 25°C | 48A (Ta) |
| Drive Voltage (Max Rds On, Min Rds On) | 5V |
| Rds On (Max) @ Id, Vgs | 3.8mOhm @ 25A, 5V |
| Vgs(th) (Max) @ Id | 2.5V @ 7mA |
| Vgs (Max) | +6V, -4V |
| Input Capacitance (Ciss) (Max) @ Vds | 2366 pF @ 50 V |
| FET Feature | - |
| Power Dissipation (Max) | - |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Supplier Device Package | 7-QFN (3x5) |
| Package / Case | 7-PowerWQFN |
| Base Product Number | - |
| Gate Charge (Qg) (Max) @ Vgs | 16.3 nC @ 5 V |
| Grade | - |
| Qualification | - |
