EPM25752V-05R-12RS
lmages are for reference only.EPM25752V-05R-12RS
DC DC CONV 60W 18-75VIN 5VOUT
Datasheet6-DIP Module
59,431 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Isolated Module DC DC Converter 1 Output 5V 12A 18V - 75V Input
EPM25752V-05R-12RS
| Category | Power Supplies - Board Mount - DC DC Converters - |
| Manufacturer | Eaton - Electronics Division |
| Series | EPM25-2V (60W) |
| Packaging | Tray |
| RoHS Status | |
| Type | Isolated Module |
| Number of Outputs | 1 |
| Voltage - Input (Min) | 18V |
| Voltage - Input (Max) | 75V |
| Voltage - Output 1 | 5V |
| Voltage - Output 2 | - |
| Voltage - Output 3 | - |
| Voltage - Output 4 | - |
| Current - Output (Max) | 12A |
| Power (Watts) | 60 W |
| Applications | ITE (Commercial) |
| Features | Adjustable Output, Remote On/Off |
| Operating Temperature | -40°C ~ 105°C (With Derating) |
| Efficiency | 91% |
| Grade | - |
| Qualification | - |
| Mounting Type | Through Hole |
| Package / Case | 6-DIP Module |
| Size / Dimension | 2.00" L x 1.00" W x 0.41" H (50.8mm x 25.4mm x 10.5mm) |
| Supplier Device Package | - |
| Control Features | - |
| Approval Agency | - |
| Standard Number | 62368-1 |
| Base Product Number | - |
| Voltage - Isolation | 1.6 kV |
| Product Attribute |  |
 |
 |
 |
| Part Number | EPM25752V-05R-8R0S | EPM25752V-12R-1R6D | EPM25752V-12R-2R5D | EPM25752V-12R-3R3S |
| Manufacturer | Eaton - Electronics Division | Eaton - Electronics Division | Eaton - Electronics Division | Eaton - Electronics Division |
| RoHS Status | ||||
| Description | DC DC CONV 40W 18-75VIN 5VOUT 8A | DC DC CONV 40W 18-75VIN 12VOUT | DC DC CONV 60W 18-75VIN 12VOUT | DC DC CONV 40W 18-75VIN 12VOUT |
| Series | Eaton - Electronics Division | Eaton - Electronics Division | Eaton - Electronics Division | Eaton - Electronics Division |
| Packaging | Tray | Tray | Tray | Tray |
