Product CatalogPart Number
ESD321DPYR
Manufacturer
Texas InstrumentsDescription
TVS DIODE 3.6VWM 6.8VC 2X1SON
Datasheet
DatasheetPackage
0402 (1006 Metric)
In Stock
25,261 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
ESD321DPYR
ESD321DPYR
lmages are for reference only.Payment Methods
Delivery Services
6.8V (Typ) Clamp 6A (8/20µs) Ipp Tvs Diode Surface Mount 2-X1SON (1x.60)
Quick Inquiry
ESD321DPYR
Specifications
| Category | Circuit Protection - Transient Voltage Suppressors TVS - TVS Diodes |
| Manufacturer | Texas Instruments |
| Series | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Type | Zener |
| Bidirectional Channels | - |
| Voltage - Reverse Standoff (Typ) | 3.6V (Max) |
| Voltage - Breakdown (Min) | 4.5V |
| Voltage - Clamping (Max) @ Ipp | 6.8V (Typ) |
| Current - Peak Pulse (10/1000µs) | 6A (8/20µs) |
| Power - Peak Pulse | 40W |
| Power Line Protection | No |
| Applications | General Purpose |
| Capacitance @ Frequency | 0.9pF @ 1MHz |
| Operating Temperature | -40°C ~ 125°C (TA) |
| Mounting Type | Surface Mount |
| Package / Case | 0402 (1006 Metric) |
| Supplier Device Package | 2-X1SON (1x.60) |
| Base Product Number | ESD321 |
| Unidirectional Channels | 1 |
| Grade | - |
| Qualification | - |
