ESD5Z5.0
lmages are for reference only.ESD5Z5.0
TVS DIODE 5V VBR MIN 6.2V SOD-
DatasheetSC-79, SOD-523
81,301 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
18.6V Clamp 9.4A Ipp Tvs Diode Surface Mount SOD-523
ESD5Z5.0
| Category | Circuit Protection - Transient Voltage Suppressors TVS - TVS Diodes |
| Manufacturer | ANBON SEMICONDUCTOR (INT'L) LIMITED |
| Series | ESD5Z |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Type | Zener |
| Bidirectional Channels | - |
| Voltage - Reverse Standoff (Typ) | 5V (Max) |
| Voltage - Breakdown (Min) | 6.2V |
| Voltage - Clamping (Max) @ Ipp | 18.6V |
| Current - Peak Pulse (10/1000µs) | 9.4A |
| Power - Peak Pulse | 174W |
| Power Line Protection | No |
| Applications | General Purpose |
| Capacitance @ Frequency | 80pF @ 1MHz |
| Operating Temperature | -40°C ~ 125°C (TA) |
| Mounting Type | Surface Mount |
| Package / Case | SC-79, SOD-523 |
| Supplier Device Package | SOD-523 |
| Base Product Number | - |
| Unidirectional Channels | 1 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
|
 |
|
| Part Number | ESD5Z5.0C | ESD5Z5.0T1 | ESD5Z5.0T1G | ESD5Z5.0T5G |
| Manufacturer | ANBON SEMICONDUCTOR (INT'L) LIMITED | onsemi | onsemi | onsemi |
| RoHS Status | ROHS3 Compliant | RoHS non-compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | TVS DIODE 5V VBR MIN 5.6V SOD- | TVS DIODE 5VWM 18.6VC SOD523 | TVS DIODE 5VWM 18.6VC SOD523 | TVS DIODE 5VWM 18.6VC SOD523 |
| Series | ANBON SEMICONDUCTOR (INT'L) LIMITED | onsemi | onsemi | onsemi |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
