Product CatalogPart Number
ESDH3V0D5B-TP
Manufacturer
Micro Commercial CoDescription
DIODE ESD PROTECTION SOD-523
Datasheet
DatasheetPackage
SC-79, SOD-523
In Stock
73,216 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
ESDH3V0D5B-TP
ESDH3V0D5B-TP
lmages are for reference only.Payment Methods
Delivery Services
13V Clamp 25A (8/20µs) Ipp Tvs Diode Surface Mount SOD-523
Quick Inquiry
ESDH3V0D5B-TP
Specifications
| Category | Circuit Protection - Transient Voltage Suppressors TVS - TVS Diodes |
| Manufacturer | Micro Commercial Co |
| Series | - |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| Type | Zener |
| Bidirectional Channels | 1 |
| Voltage - Reverse Standoff (Typ) | 3.3V (Max) |
| Voltage - Breakdown (Min) | 3.8V |
| Voltage - Clamping (Max) @ Ipp | 13V |
| Current - Peak Pulse (10/1000µs) | 25A (8/20µs) |
| Power - Peak Pulse | 325W |
| Power Line Protection | No |
| Applications | General Purpose |
| Capacitance @ Frequency | 36pF @ 1MHz |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | SC-79, SOD-523 |
| Supplier Device Package | SOD-523 |
| Base Product Number | ESDH3V0 |
| Unidirectional Channels | - |
| Grade | - |
| Qualification | - |
