FAN3122CMX
Manufacturer
onsemiDescription
IC GATE DRVR LOW-SIDE 8SOIC
Datasheet
DatasheetPackage
8-SOIC (0.154", 3.90mm Width)
In Stock
35,823 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
FAN3122CMX
FAN3122CMX
lmages are for reference only.Payment Methods
Delivery Services
Low-Side Gate Driver IC Non-Inverting 8-SOIC
Quick Inquiry
FAN3122CMX
Specifications
| Category | Integrated Circuits (ICs) - Power Management PMIC - Gate Drivers |
| Manufacturer | onsemi |
| Series | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Driven Configuration | Low-Side |
| Channel Type | Single |
| Number of Drivers | 1 |
| Gate Type | N-Channel MOSFET |
| Voltage - Supply | 4.5V ~ 18V |
| Logic Voltage - VIL, VIH | - |
| Current - Peak Output (Source, Sink) | 10.6A, 11.4A |
| Input Type | Non-Inverting |
| High Side Voltage - Max (Bootstrap) | - |
| Rise / Fall Time (Typ) | 23ns, 19ns |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | 8-SOIC (0.154", 3.90mm Width) |
| Supplier Device Package | 8-SOIC |
| Base Product Number | FAN3122 |
| Grade | - |
| Qualification | - |
