FAN501MPX
lmages are for reference only.FAN501MPX
IC OFFLINE SWITCH FLYBACK 10MLP
Datasheet10-WQFN Exposed Pad
62,983 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Converter Offline Flyback Topology 85kHz ~ 140kHz 10-MLP (4x3)
FAN501MPX
| Category | Integrated Circuits (ICs) - Power Management PMIC - AC DC Converters-Offline Switches |
| Manufacturer | Fairchild Semiconductor |
| Series | WSaver® |
| Packaging | Bulk |
| RoHS Status | |
| Output Isolation | Isolated |
| Internal Switch(s) | No |
| Voltage - Breakdown | - |
| Topology | Flyback |
| Voltage - Supply (Vcc/Vdd) | 5.8V ~ 30V |
| Duty Cycle | 68.5% |
| Frequency - Switching | 85kHz ~ 140kHz |
| Power (Watts) | - |
| Fault Protection | Current Limiting, Over Temperature, Over Voltage |
| Control Features | - |
| Operating Temperature | -40°C ~ 125°C (TA) |
| Package / Case | 10-WQFN Exposed Pad |
| Supplier Device Package | 10-MLP (4x3) |
| Mounting Type | Surface Mount |
| Base Product Number | FAN501 |
| Voltage - Start Up | 17.5 V |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | FAN501MPX | FAN501AMPX | FAN501AMPX | FAN501ARMPX |
| Manufacturer | onsemi | Fairchild Semiconductor | onsemi | Fairchild Semiconductor |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ||
| Description | IC OFFLINE SWITCH FLYBACK 10MLP | IC OFFLINE SWITCH FLYBACK 10MLP | IC OFFLINE SWITCH FLYBACK 10MLP | FAN501A - OFFLINE DCM/CCM FLYBAC |
| Series | WSaver® | WSaver® | WSaver® | * |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Bulk | Tape & Reel (TR) | Bulk |
