FAN5608MPX
lmages are for reference only.FAN5608MPX
IC LED DRVR RGLTR PWM 20MA 8MLP
Datasheet8-WDFN Exposed Pad
58,613 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
LED Driver IC 2 Output DC DC Regulator Step-Up (Boost) PWM Dimming 20mA 8-MLP (3x3)
FAN5608MPX
| Category | Integrated Circuits (ICs) - Power Management PMIC - LED Drivers |
| Manufacturer | Fairchild Semiconductor |
| Series | - |
| Packaging | Bulk |
| RoHS Status | ROHS3 Compliant |
| Type | DC DC Regulator |
| Topology | Step-Up (Boost) |
| Internal Switch(s) | Yes |
| Number of Outputs | 2 |
| Voltage - Supply (Min) | 2.7V |
| Voltage - Supply (Max) | 5.5V |
| Voltage - Output | 18V |
| Current - Output / Channel | 20mA |
| Frequency | 500kHz |
| Dimming | PWM |
| Applications | Backlight |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Mounting Type | Surface Mount |
| Package / Case | 8-WDFN Exposed Pad |
| Supplier Device Package | 8-MLP (3x3) |
| Base Product Number | FAN5608 |
| Grade | - |
| Qualification | - |
| Product Attribute | |
 |
 |
 |
| Part Number | FAN5608MPX | FAN5608DHMPX | FAN5608DMPX | FAN5608HMPX |
| Manufacturer | onsemi | onsemi | onsemi | onsemi |
| RoHS Status | ||||
| Description | IC LED DRVR RGLTR PWM 20MA 8MLP | IC LED DRVR RGLTR PWM 20MA 12MLP | IC LED DRVR RGLTR PWM 20MA 8MLP | IC LED DRVR RGLTR PWM 20MA 12MLP |
| Series | - | - | - | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
