FCBA1-1210F-10NJ
lmages are for reference only.FCBA1-1210F-10NJ
FIXED IND 10NH 1000MA 0.08 MOHM
Datasheet1210 (3225 Metric)
46,128 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
10 nH Unshielded Wirewound Inductor 1 A 80mOhm Max 1210 (3225 Metric)
FCBA1-1210F-10NJ
| Category | Inductors, Coils, Chokes - Fixed Inductors - |
| Manufacturer | Signal Transformer |
| Series | FCBA1-1210 |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| Type | Wirewound |
| Material - Core | Ferrite |
| Inductance | 10 nH |
| Tolerance | ±5% |
| Current Rating (Amps) | 1 A |
| Current - Saturation (Isat) | - |
| Shielding | Unshielded |
| DC Resistance (DCR) | 80mOhm Max |
| Q @ Freq | 40 @ 300MHz |
| Frequency - Self Resonant | 4GHz |
| Ratings | - |
| Operating Temperature | -40°C ~ 125°C |
| Inductance Frequency - Test | 100 MHz |
| Features | - |
| Mounting Type | Surface Mount |
| Package / Case | 1210 (3225 Metric) |
| Supplier Device Package | 1210 |
| Size / Dimension | 0.140" L x 0.115" W (3.56mm x 2.92mm) |
| Height - Seated (Max) | 0.089" (2.25mm) |
| Base Product Number | - |
| Product Attribute |  |
|
 |
 |
| Part Number | FCBA1-1210F-100J | FCBA1-1210F-100J | FCBA1-1210F-12NJ | FCBA1-1210F-15NJ |
| Manufacturer | Signal Transformer | Signal Transformer | Signal Transformer | Signal Transformer |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | FIXED IND 10000NH 200MA 6.8 MOHM | FIXED IND 10000NH 200MA 6.8 MOHM | FIXED IND 12NH 1000MA 0.08 MOHM | FIXED IND 15NH 1000MA 0.1 MOHM |
| Series | Signal Transformer | Signal Transformer | Signal Transformer | Signal Transformer |
| Packaging | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) |
