FDM2509NZ
Manufacturer
onsemiDescription
MOSFET 2N-CH 20V 8.7A MICRO 2X2
Datasheet
DatasheetPackage
6-UDFN Exposed Pad
In Stock
33,751 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
FDM2509NZ
FDM2509NZ
lmages are for reference only.Payment Methods
Delivery Services
Mosfet Array 20V 8.7A 800mW Surface Mount MicroFET 2x2 Thin
Quick Inquiry
FDM2509NZ
Specifications
| Category | Discrete Semiconductor Products - Transistors - FETs-MOSFETs |
| Manufacturer | onsemi |
| Series | PowerTrench® |
| Packaging | Tape & Reel (TR) |
| RoHS Status | |
| Technology | MOSFET (Metal Oxide) |
| Configuration | 2 N-Channel (Dual) |
| FET Feature | Logic Level Gate |
| Drain to Source Voltage (Vdss) | 20V |
| Current - Continuous Drain (Id) @ 25°C | 8.7A |
| Rds On (Max) @ Id, Vgs | 18mOhm @ 8.7A, 4.5V |
| Vgs(th) (Max) @ Id | 1.5V @ 250µA |
| Gate Charge (Qg) (Max) @ Vgs | 17nC @ 4.5V |
| Input Capacitance (Ciss) (Max) @ Vds | 1200pF @ 10V |
| Power - Max | 800mW |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | 6-UDFN Exposed Pad |
| Supplier Device Package | MicroFET 2x2 Thin |
| Base Product Number | FDM2509 |
| Grade | - |
| Qualification | - |
