FDMS003N08C
Manufacturer
onsemiDescription
MOSFET N-CH 80V 22A/147A POWER56
Datasheet
DatasheetPackage
8-PowerTDFN
In Stock
86,037 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
FDMS003N08C
FDMS003N08C
lmages are for reference only.Payment Methods
Delivery Services
N-Channel 80 V 22A (Ta), 147A (Tc) 2.7W (Ta), 125W (Tc) Surface Mount Power56
Quick Inquiry
FDMS003N08C
Specifications
| Category | Discrete Semiconductor Products - Transistors - FETs-MOSFETs |
| Manufacturer | onsemi |
| Series | PowerTrench® |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| FET Type | N-Channel |
| Technology | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 80 V |
| Current - Continuous Drain (Id) @ 25°C | 22A (Ta), 147A (Tc) |
| Drive Voltage (Max Rds On, Min Rds On) | 6V, 10V |
| Rds On (Max) @ Id, Vgs | 3.1mOhm @ 56A, 10V |
| Vgs(th) (Max) @ Id | 4V @ 310µA |
| Vgs (Max) | ±20V |
| Input Capacitance (Ciss) (Max) @ Vds | 5350 pF @ 40 V |
| FET Feature | - |
| Power Dissipation (Max) | 2.7W (Ta), 125W (Tc) |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Supplier Device Package | Power56 |
| Package / Case | 8-PowerTDFN |
| Base Product Number | FDMS003 |
| Gate Charge (Qg) (Max) @ Vgs | 73 nC @ 10 V |
| Grade | - |
| Qualification | - |
