Product CatalogPart Number
FDMS7670
Manufacturer
onsemiDescription
MOSFET N-CH 30V 21A/42A 8PQFN
Datasheet
DatasheetPackage
8-PowerTDFN
In Stock
69,329 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
FDMS7670
FDMS7670
lmages are for reference only.Payment Methods
Delivery Services
N-Channel 30 V 21A (Ta), 42A (Tc) 2.5W (Ta), 62W (Tc) Surface Mount 8-PQFN (5x6)
Quick Inquiry
FDMS7670
Specifications
| Category | Discrete Semiconductor Products - Transistors - FETs-MOSFETs |
| Manufacturer | onsemi |
| Series | PowerTrench® |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| FET Type | N-Channel |
| Technology | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 30 V |
| Current - Continuous Drain (Id) @ 25°C | 21A (Ta), 42A (Tc) |
| Drive Voltage (Max Rds On, Min Rds On) | 4.5V, 10V |
| Rds On (Max) @ Id, Vgs | 3.8mOhm @ 21A, 10V |
| Vgs(th) (Max) @ Id | 3V @ 250µA |
| Vgs (Max) | ±20V |
| Input Capacitance (Ciss) (Max) @ Vds | 4105 pF @ 15 V |
| FET Feature | - |
| Power Dissipation (Max) | 2.5W (Ta), 62W (Tc) |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Supplier Device Package | 8-PQFN (5x6) |
| Package / Case | 8-PowerTDFN |
| Base Product Number | FDMS76 |
| Gate Charge (Qg) (Max) @ Vgs | 56 nC @ 10 V |
| Grade | - |
| Qualification | - |
Parts with Similar Specifications
| Product Attribute | |
 |
 |
|
| Part Number | FDMS7670 | FDMS7670AS | FDMS7672 | FDMS7672 |
| Manufacturer | Fairchild Semiconductor | onsemi | Fairchild Semiconductor | onsemi |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ||
| Description | POWER FIELD-EFFECT TRANSISTOR, 2 | MOSFET N-CH 30V 22A/42A 8PQFN | POWER FIELD-EFFECT TRANSISTOR, 1 | MOSFET N-CH 30V 19A/28A 8PQFN |
| Series | PowerTrench® | PowerTrench®, SyncFET™ | PowerTrench® | PowerTrench® |
| Packaging | Bulk | Tape & Reel (TR)-->Cut Tape (CT) | Bulk | Tape & Reel (TR)-->Cut Tape (CT) |
