FDMS8023S

FDMS8023S

FDMS8023S

lmages are for reference only.
  • Part Number

    FDMS8023S

  • Manufacturer

    Fairchild Semiconductor
  • Description

    POWER FIELD-EFFECT TRANSISTOR, 2

  • Datasheet

    DatasheetDatasheet
  • Package

    8-PowerTDFN

  • In Stock

    16,201 piece(s)

  • Unit Price

    Please Contact Us

  • Lead Time

    Can Ship Immediately

Request for Quotation

  • Payment Methods

  • Delivery Services

N-Channel 30 V 26A (Ta), 49A (Tc) 2.5W (Ta), 59W (Tc) Surface Mount 8-PQFN (5x6)

Quick Inquiry

FDMS8023S

Get the Price Now!

Specifications

Category Discrete Semiconductor Products - Transistors - FETs-MOSFETs
Manufacturer Fairchild Semiconductor
Series PowerTrench®, SyncFET™
Packaging Bulk
RoHS Status
FET Type N-Channel
Technology MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss) 30 V
Current - Continuous Drain (Id) @ 25°C 26A (Ta), 49A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 4.5V, 10V
Rds On (Max) @ Id, Vgs 2.4mOhm @ 26A, 10V
Vgs(th) (Max) @ Id 3V @ 1mA
Vgs (Max) ±20V
Input Capacitance (Ciss) (Max) @ Vds 3550 pF @ 15 V
FET Feature -
Power Dissipation (Max) 2.5W (Ta), 59W (Tc)
Operating Temperature -55°C ~ 150°C (TJ)
Mounting Type Surface Mount
Supplier Device Package 8-PQFN (5x6)
Package / Case 8-PowerTDFN
Base Product Number -
Gate Charge (Qg) (Max) @ Vgs 57 nC @ 10 V
Grade -
Qualification -

Parts with Similar Specifications

Product Attribute FDMS8023S FDMS8018 FDMS8020 FDMS8025S
Part Number FDMS8023S FDMS8018 FDMS8020 FDMS8025S
Manufacturer onsemi onsemi onsemi Fairchild Semiconductor
RoHS Status ROHS3 Compliant ROHS3 Compliant ROHS3 Compliant
Description MOSFET N-CH 30V 26A/49A 8PQFN MOSFET N-CH 30V 30A/120A 8PQFN MOSFET N-CH 30V 26A/42A 8PQFN MOSFET N-CH 30V 24A/49A 8PQFN
Series PowerTrench®, SyncFET™ PowerTrench® PowerTrench® PowerTrench®, SyncFET™
Packaging Tape & Reel (TR)-->Cut Tape (CT) Tape & Reel (TR)-->Cut Tape (CT) Tape & Reel (TR)-->Cut Tape (CT) Bulk
