FIT50-3-B
lmages are for reference only.FIT50-3-B
FIXED IND 27.16UH 4A 40.1MOHM TH
DatasheetRadial, Vertical (Open)
53,400 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
27.16 µH Unshielded Toroidal Inductor 4 A 40.1mOhm Max Radial, Vertical (Open)
FIT50-3-B
| Category | Inductors, Coils, Chokes - Fixed Inductors - |
| Manufacturer | Triad Magnetics |
| Series | FIT |
| Packaging | Bulk |
| RoHS Status | ROHS3 Compliant |
| Type | Toroidal |
| Material - Core | Iron Powder |
| Inductance | 27.16 µH |
| Tolerance | - |
| Current Rating (Amps) | 4 A |
| Current - Saturation (Isat) | - |
| Shielding | Unshielded |
| DC Resistance (DCR) | 40.1mOhm Max |
| Q @ Freq | - |
| Frequency - Self Resonant | - |
| Ratings | - |
| Operating Temperature | -40°C ~ 85°C |
| Inductance Frequency - Test | 10 kHz |
| Features | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Vertical (Open) |
| Supplier Device Package | - |
| Size / Dimension | 0.700" L x 0.475" W (17.78mm x 12.07mm) |
| Height - Seated (Max) | 0.750" (19.05mm) |
| Base Product Number | - |
| Product Attribute |  |
|
 |
|
| Part Number | FIT50-1 | FIT50-1-B | FIT50-2 | FIT50-2-B |
| Manufacturer | Triad Magnetics | Triad Magnetics | Triad Magnetics | Triad Magnetics |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | FIXED IND 47.4UH 2.8A 78.9 MOHM | FIXED IND 47.4UH 2.8A 78.9 MOHM | FIXED IND 35.48UH 3.4A 57.8 MOHM | FIXED IND 35.48UH 3.4A 57.8 MOHM |
| Series | Triad Magnetics | Triad Magnetics | Triad Magnetics | Triad Magnetics |
| Packaging | Bulk | Bulk | Bulk | Bulk |
