Product CatalogPart Number
FMVC13001
Manufacturer
Fairview MicrowaveDescription
VOLT CONTROL OSC 18MHZ-30MHZ
Datasheet
DatasheetPackage
4-SMD, Flat Leads
In Stock
65,980 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
FMVC13001
FMVC13001
lmages are for reference only.Payment Methods
Delivery Services
24MHz Center Frequency 0 V ~ 12 V Voltage Controlled Oscillator 12 -2, +1.5 dBm -13 2nd Harmonic Typ (dBc)
Quick Inquiry
FMVC13001
Specifications
| Category | Crystals, Oscillators, Resonators - VCOs Voltage Controlled Oscillators - |
| Manufacturer | Fairview Microwave |
| Series | - |
| Packaging | Bag |
| RoHS Status | |
| Frequency Range | 18 ~ 30MHz |
| Frequency - Center | 24MHz |
| Voltage - Supply | 12V |
| Tuning Voltage (VDC) | 0 V ~ 12 V |
| 2nd Harmonic, Typ (dBc) | -13 |
| Icc Max | 19mA |
| Pushing (MHz/V) | 1.8 |
| Power (dBm) | 12 -2, +1.5 |
| Phase Noise Typ (dBc/Hz) | -120 |
| Operating Temperature | -40°C ~ 85°C |
| Package / Case | 4-SMD, Flat Leads |
| Size / Dimension | 0.500" L x 0.500" W (12.70mm x 12.70mm) |
| Height | 0.252" (6.40mm) |
| Base Product Number | - |
Parts with Similar Specifications
| Product Attribute | |
|
 |
|
| Part Number | FMVC13001 | FMVC13001 | FMVC13011 | FMVC13011 |
| Manufacturer | Fairview Microwave | Fairview Microwave | Fairview Microwave | Fairview Microwave |
| RoHS Status | ||||
| Description | VOLT CONTROL OSC 18MHZ-30MHZ | VOLT CONTROL OSC 18MHZ-30MHZ | VOLT CONTROL OSC 200MHZ-400MHZ | VOLT CONTROL OSC 200MHZ-400MHZ |
| Series | - | - | - | - |
| Packaging | Bag | Bag | Bag | Bag |
