FN7660-10-M3
lmages are for reference only.FN7660-10-M3
FILTER LC(PI) 58NH/0.01UF BOLT
DatasheetAxial - Threaded Terminals
28,120 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
LC (Pi) EMI Filter 3rd Order Low Pass 1 Channel L = 58nH, C = 10000pF 10 A Axial - Threaded Terminals
FN7660-10-M3
| Category | Filters - EMI-RFI Filters LC-RC Networks - |
| Manufacturer | Schaffner EMC Inc. |
| Series | FN 766X |
| Packaging | Tray |
| RoHS Status | ROHS3 Compliant |
| Type | Low Pass |
| Filter Order | 3rd |
| Technology | LC (Pi) |
| Center / Cutoff Frequency | - |
| Attenuation Value | - |
| Resistance - Channel (Ohms) | 0.00106 |
| Current | 10 A |
| Values | L = 58nH, C = 10000pF |
| ESD Protection | No |
| Operating Temperature | -40°C ~ 100°C |
| Applications | Data Lines for Mobile Devices |
| Voltage - Rated | 130V |
| Mounting Type | Bolt Mount |
| Package / Case | Axial - Threaded Terminals |
| Size / Dimension | 0.787" Dia x 2.402" L (20.00mm x 61.00mm) |
| Height | - |
| Number of Channels | 1 |
| Base Product Number | FN7660 |
| Grade | - |
| Qualification | - |
| Product Attribute | |
 |
|
 |
| Part Number | FN7660-10-M3 | FN7660-100-M8 | FN7660-100-M8 | FN7660-200-M10 |
| Manufacturer | Schaffner EMC Inc. | Schaffner EMC Inc. | Schaffner EMC Inc. | Schaffner EMC Inc. |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | FILTER LC(PI) 58NH/0.01UF BOLT | FILTER LC(PI) 124NH/0.47UF BOLT | FILTER LC(PI) 124NH/0.47UF BOLT | FILTER LC(PI) 124NH/0.47UF BOLT |
| Series | FN 766X | FN 766X | FN 766X | FN 766X |
| Packaging | Tray | Tray | Tray | Tray |
