Product CatalogPart Number
FOD815300W
Manufacturer
onsemiDescription
OPTOISOLATOR 5KV DARLINGTON 4DIP
Datasheet
DatasheetPackage
4-DIP (0.400", 10.16mm)
In Stock
59,302 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
FOD815300W
FOD815300W
lmages are for reference only.Payment Methods
Delivery Services
Optoisolator Darlington Output 5000Vrms 1 Channel 4-DIP
Quick Inquiry
FOD815300W
Specifications
| Category | Isolators - Optoisolators - Transistor-Photovoltaic Output Optoisolators |
| Manufacturer | onsemi |
| Series | - |
| Packaging | Box |
| RoHS Status | |
| Number of Channels | 1 |
| Voltage - Isolation | 5000Vrms |
| Current Transfer Ratio (Min) | 600% @ 1mA |
| Current Transfer Ratio (Max) | 7500% @ 1mA |
| Turn On / Turn Off Time (Typ) | - |
| Rise / Fall Time (Typ) | 60µs, 53µs |
| Input Type | DC |
| Output Type | Darlington |
| Voltage - Output (Max) | 35V |
| Current - Output / Channel | 80mA |
| Voltage - Forward (Vf) (Typ) | 1.2V |
| Current - DC Forward (If) (Max) | 50 mA |
| Vce Saturation (Max) | 1V |
| Operating Temperature | -30°C ~ 105°C |
| Mounting Type | Through Hole |
| Package / Case | 4-DIP (0.400", 10.16mm) |
| Supplier Device Package | 4-DIP |
| Base Product Number | FOD815 |
| Grade | - |
| Qualification | - |
