Product CatalogPart Number
FOD8480R2
Manufacturer
onsemiDescription
OPTOISO 5KV 1CH GATE DVR 6SOIC
Datasheet
DatasheetPackage
6-SOIC (0.268", 6.80mm Width)
In Stock
89,922 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
FOD8480R2
FOD8480R2
lmages are for reference only.Payment Methods
Delivery Services
Gate Driver Optical Coupling 5000Vrms 1 Channel 6-SOIC
Quick Inquiry
FOD8480R2
Specifications
| Category | Isolators - Isolators Gate Drivers - |
| Manufacturer | onsemi |
| Series | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Technology | Optical Coupling |
| Number of Channels | 1 |
| Voltage - Isolation | 5000Vrms |
| Common Mode Transient Immunity (Min) | 20kV/µs |
| Propagation Delay tpLH / tpHL (Max) | 300ns, 300ns |
| Pulse Width Distortion (Max) | 250ns |
| Rise / Fall Time (Typ) | 15ns, 10ns |
| Current - Output High, Low | 2.5mA, 2.5mA |
| Current - Peak Output | - |
| Voltage - Forward (Vf) (Typ) | 1.4V |
| Voltage - Output Supply | 4.5V ~ 30V |
| Grade | - |
| Qualification | - |
| Operating Temperature | -40°C ~ 100°C |
| Mounting Type | Surface Mount |
| Package / Case | 6-SOIC (0.268", 6.80mm Width) |
| Supplier Device Package | 6-SOIC |
| Approval Agency | IEC/EN/DIN, UL |
| Base Product Number | FOD8480 |
| Current - DC Forward (If) (Max) | 20 mA |
Parts with Similar Specifications
| Product Attribute |  |
 |
 |
 |
| Part Number | FOD8480R2V | FOD8480 | FOD8480T | FOD8480TR2 |
| Manufacturer | onsemi | onsemi | onsemi | onsemi |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | OPTOISO 5KV 1CH GATE DVR 6SOIC | OPTOISO 5KV 1CH GATE DVR 6SOIC | OPTOISO 5KV 1CH GATE DVR 6SOIC | OPTOISO 5KV 1CH GATE DVR 6SOIC |
| Series | onsemi | onsemi | onsemi | onsemi |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tube | Tube | Tape & Reel (TR)-->Cut Tape (CT) |
