FP1107R1-R51-R
lmages are for reference only.FP1107R1-R51-R
FIXED IND 510NH 55A 0.29MOHM SMD
DatasheetNonstandard
47,463 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
510 nH Unshielded Drum Core, Wirewound Inductor 55 A 0.29mOhm Nonstandard
FP1107R1-R51-R
| Category | Inductors, Coils, Chokes - Fixed Inductors - |
| Manufacturer | Eaton - Electronics Division |
| Series | FLAT-PAC, FP1107 |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | RoHS Compliant |
| Type | Drum Core, Wirewound |
| Material - Core | Ferrite |
| Inductance | 510 nH |
| Tolerance | ±10% |
| Current Rating (Amps) | 55 A |
| Current - Saturation (Isat) | 18A |
| Shielding | Unshielded |
| DC Resistance (DCR) | 0.29mOhm |
| Q @ Freq | - |
| Frequency - Self Resonant | - |
| Ratings | - |
| Operating Temperature | -40°C ~ 125°C |
| Inductance Frequency - Test | 100 kHz |
| Features | - |
| Mounting Type | Surface Mount |
| Package / Case | Nonstandard |
| Supplier Device Package | - |
| Size / Dimension | 0.433" L x 0.283" W (11.00mm x 7.20mm) |
| Height - Seated (Max) | 0.295" (7.50mm) |
| Base Product Number | - |
| Product Attribute |  |
|
 |
 |
| Part Number | FP1107R1-R07-R | FP1107R1-R07-R | FP1107R1-R12-R | FP1107R1-R15-R |
| Manufacturer | Eaton - Electronics Division | Eaton - Electronics Division | Eaton - Electronics Division | Eaton - Electronics Division |
| RoHS Status | RoHS Compliant | RoHS Compliant | RoHS Compliant | ROHS3 Compliant |
| Description | FIXED IND 70NH 55A 0.29 MOHM SMD | FIXED IND 70NH 55A 0.29 MOHM SMD | FIXED IND 120NH 55A 0.29MOHM SMD | FIXED IND 150NH 55A 0.29MOHM SMD |
| Series | Eaton - Electronics Division | Eaton - Electronics Division | Eaton - Electronics Division | Eaton - Electronics Division |
| Packaging | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR)-->Cut Tape (CT) |
