FQPF3N80CYDTU
lmages are for reference only.FQPF3N80CYDTU
MOSFET N-CH 800V 3A TO220F-3
DatasheetTO-220-3 Full Pack, Formed Leads
95,699 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
N-Channel 800 V 3A (Tc) 39W (Tc) Through Hole TO-220F-3 (Y-Forming)
FQPF3N80CYDTU
| Category | Discrete Semiconductor Products - Transistors - FETs-MOSFETs |
| Manufacturer | Fairchild Semiconductor |
| Series | QFET® |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| FET Type | N-Channel |
| Technology | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 800 V |
| Current - Continuous Drain (Id) @ 25°C | 3A (Tc) |
| Drive Voltage (Max Rds On, Min Rds On) | 10V |
| Rds On (Max) @ Id, Vgs | 4.8Ohm @ 1.5A, 10V |
| Vgs(th) (Max) @ Id | 5V @ 250µA |
| Vgs (Max) | ±30V |
| Input Capacitance (Ciss) (Max) @ Vds | 705 pF @ 25 V |
| FET Feature | - |
| Power Dissipation (Max) | 39W (Tc) |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Through Hole |
| Supplier Device Package | TO-220F-3 (Y-Forming) |
| Package / Case | TO-220-3 Full Pack, Formed Leads |
| Base Product Number | - |
| Gate Charge (Qg) (Max) @ Vgs | 16.5 nC @ 10 V |
| Grade | - |
| Qualification | - |
| Product Attribute | |
 |
|
 |
| Part Number | FQPF3N80CYDTU | FQPF3N80 | FQPF3N80 | FQPF3N80C |
| Manufacturer | onsemi | onsemi | Fairchild Semiconductor | onsemi |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ||
| Description | MOSFET N-CH 800V 3A TO220F-3 | MOSFET N-CH 800V 1.8A TO220F | MOSFET N-CH 800V 1.8A TO220F | MOSFET N-CH 800V 3A TO220F |
| Series | QFET® | QFET® | QFET® | QFET® |
| Packaging | Tube | Tube | Tube | Tube |
