G7P03D2
lmages are for reference only.G7P03D2
P-30V,-7A,RD(MAX)<20.5M@-10V,VTH
Datasheet6-WDFN Exposed Pad
36,243 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
P-Channel 30 V 7A (Tc) 1.3W (Tc) Surface Mount 6-DFN (2x2)
G7P03D2
| Category | Discrete Semiconductor Products - Transistors - FETs-MOSFETs |
| Manufacturer | Goford Semiconductor |
| Series | - |
| Packaging | Tape & Reel (TR) |
| RoHS Status | RoHS Compliant |
| FET Type | P-Channel |
| Technology | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 30 V |
| Current - Continuous Drain (Id) @ 25°C | 7A (Tc) |
| Drive Voltage (Max Rds On, Min Rds On) | 4.5V, 10V |
| Rds On (Max) @ Id, Vgs | 20.5mOhm @ 1A, 10V |
| Vgs(th) (Max) @ Id | 1.1V @ 250µA |
| Vgs (Max) | ±20V |
| Input Capacitance (Ciss) (Max) @ Vds | 1900 pF @ 15 V |
| FET Feature | - |
| Power Dissipation (Max) | 1.3W (Tc) |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Supplier Device Package | 6-DFN (2x2) |
| Package / Case | 6-WDFN Exposed Pad |
| Base Product Number | - |
| Gate Charge (Qg) (Max) @ Vgs | 19 nC @ 4.5 V |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | G7P03L | G7P03S | G29 | GT025N06AT |
| Manufacturer | Goford Semiconductor | Goford Semiconductor | Goford Semiconductor | Goford Semiconductor |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | P30V,RD(MAX)<23M@-10V,RD(MAX)<34 | P30V,RD(MAX)<22M@-10V,RD(MAX)<33 | P15V,RD(MAX)<30M@-4.5V,RD(MAX)<4 | N60V, 170A,RD<2.5M@10V,VTH1.2V~2 |
| Series | TrenchFET® | TrenchFET® | TrenchFET® | SGT |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tube |
