Product CatalogPart Number
GF4045TS-1-S1
Manufacturer
SMC Diode SolutionsDescription
PLANAR SCHOTTKY MODULE 45V 40A Q
Datasheet
DatasheetPackage
Module
In Stock
83,876 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
GF4045TS-1-S1
GF4045TS-1-S1
lmages are for reference only.Payment Methods
Delivery Services
Diode 45 V 40A Chassis Mount
Quick Inquiry
GF4045TS-1-S1
Specifications
| Category | Discrete Semiconductor Products - Diodes - Rectifiers |
| Manufacturer | SMC Diode Solutions |
| Series | - |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| Technology | Schottky |
| Voltage - DC Reverse (Vr) (Max) | 45 V |
| Current - Average Rectified (Io) | 40A |
| Voltage - Forward (Vf) (Max) @ If | 520 mV @ 40 A |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) |
| Reverse Recovery Time (trr) | - |
| Current - Reverse Leakage @ Vr | 200 µA @ 45 V |
| Capacitance @ Vr, F | 5840pF @ 5V, 1MHz |
| Mounting Type | Chassis Mount |
| Package / Case | Module |
| Supplier Device Package | - |
| Operating Temperature - Junction | -55°C ~ 200°C |
| Base Product Number | - |
| Grade | - |
| Qualification | - |
Parts with Similar Specifications
| Product Attribute |  |
 |
 |
 |
| Part Number | GF4045PC-S1 | GF4045PS-S1 | GF4045TS-S1 | VS-HFA25PB60-N3 |
| Manufacturer | SMC Diode Solutions | SMC Diode Solutions | SMC Diode Solutions | Vishay General Semiconductor - Diodes Division |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | PLANAR SCHOTTKY MODULE 45V 40A G | PLANAR SCHOTTKY MODULE 45V 40A G | TRENCH SCHOTTKY MODULE 45V 40A G | DIODE GP 600V 25A TO247AC |
| Series | - | - | - | HEXFRED® |
| Packaging | Tube | Tube | Tube | Tube |
