Product CatalogPart Number
H11A2TM
Manufacturer
onsemiDescription
OPTOISO 7.5KV TRANS W/BASE 6DIP
Datasheet
DatasheetPackage
6-DIP (0.400", 10.16mm)
In Stock
55,068 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
H11A2TM
H11A2TM
lmages are for reference only.Payment Methods
Delivery Services
Optoisolator Transistor with Base Output 7500Vpk 1 Channel 6-DIP
Quick Inquiry
H11A2TM
Specifications
| Category | Isolators - Optoisolators - Transistor-Photovoltaic Output Optoisolators |
| Manufacturer | onsemi |
| Series | - |
| Packaging | Bulk |
| RoHS Status | |
| Number of Channels | 1 |
| Voltage - Isolation | 7500Vpk |
| Current Transfer Ratio (Min) | 20% @ 10mA |
| Current Transfer Ratio (Max) | - |
| Turn On / Turn Off Time (Typ) | 2µs, 2µs |
| Rise / Fall Time (Typ) | - |
| Input Type | DC |
| Output Type | Transistor with Base |
| Voltage - Output (Max) | 30V |
| Current - Output / Channel | - |
| Voltage - Forward (Vf) (Typ) | 1.18V |
| Current - DC Forward (If) (Max) | 60 mA |
| Vce Saturation (Max) | 400mV |
| Operating Temperature | -40°C ~ 100°C |
| Mounting Type | Through Hole |
| Package / Case | 6-DIP (0.400", 10.16mm) |
| Supplier Device Package | 6-DIP |
| Base Product Number | H11A |
| Grade | - |
| Qualification | - |
