Product CatalogPart Number
H11L1FM
Manufacturer
onsemiDescription
OPTOISO 4.17KV OPN COLL 6SMD
Datasheet
DatasheetPackage
6-SMD, Gull Wing
In Stock
77,554 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
H11L1FM
H11L1FM
lmages are for reference only.Payment Methods
Delivery Services
Logic Output Optoisolator 1MHz Open Collector 4170Vrms 1 Channel CMTI 6-SMD
Quick Inquiry
H11L1FM
Specifications
| Category | Isolators - Optoisolators - Logic Output Optoisolators |
| Manufacturer | onsemi |
| Series | - |
| Packaging | Tube |
| RoHS Status | |
| Number of Channels | 1 |
| Inputs - Side 1/Side 2 | 1/0 |
| Voltage - Isolation | 4170Vrms |
| Common Mode Transient Immunity (Min) | - |
| Input Type | DC |
| Output Type | Open Collector |
| Current - Output / Channel | 50 mA |
| Data Rate | 1MHz |
| Propagation Delay tpLH / tpHL (Max) | 4µs, 4µs |
| Rise / Fall Time (Typ) | 100ns, 100ns |
| Voltage - Forward (Vf) (Typ) | 1.2V |
| Current - DC Forward (If) (Max) | 30mA |
| Voltage - Supply | 3V ~ 15V |
| Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Surface Mount |
| Package / Case | 6-SMD, Gull Wing |
| Supplier Device Package | 6-SMD |
| Base Product Number | H11L |
| Grade | - |
| Qualification | - |
Parts with Similar Specifications
| Product Attribute | |
 |
|
 |
| Part Number | H11L1FM | H11L1FR2M | H11L1FR2M | H11L1FR2VM |
| Manufacturer | onsemi | onsemi | onsemi | onsemi |
| RoHS Status | ||||
| Description | OPTOISO 4.17KV OPN COLL 6SMD | OPTOISO 4.17KV OPN COLL 6SMD | OPTOISO 4.17KV OPN COLL 6SMD | OPTOISO 4.17KV OPN COLL 6SMD |
| Series | - | - | - | - |
| Packaging | Tube | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) |
