HAT1072H-EL-E
lmages are for reference only.HAT1072H-EL-E
MOSFET P-CH 30V 40A LFPAK
DatasheetSC-100, SOT-669
29,373 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
P-Channel 30 V 40A (Ta) 30W (Tc) Surface Mount LFPAK
HAT1072H-EL-E
| Category | Discrete Semiconductor Products - Transistors - FETs-MOSFETs |
| Manufacturer | Renesas Electronics Corporation |
| Series | - |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| FET Type | P-Channel |
| Technology | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 30 V |
| Current - Continuous Drain (Id) @ 25°C | 40A (Ta) |
| Drive Voltage (Max Rds On, Min Rds On) | 4.5V, 10V |
| Rds On (Max) @ Id, Vgs | 4.5mOhm @ 20A, 10V |
| Vgs(th) (Max) @ Id | - |
| Vgs (Max) | +10V, -20V |
| Input Capacitance (Ciss) (Max) @ Vds | 9500 pF @ 10 V |
| FET Feature | - |
| Power Dissipation (Max) | 30W (Tc) |
| Operating Temperature | 150°C (TJ) |
| Mounting Type | Surface Mount |
| Supplier Device Package | LFPAK |
| Package / Case | SC-100, SOT-669 |
| Base Product Number | HAT1072 |
| Gate Charge (Qg) (Max) @ Vgs | 155 nC @ 10 V |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
|
| Part Number | HAT1035R-EL-E | HAT1038RJ-EL | HAT1041T-EL-E | HAT1043M-EL-E |
| Manufacturer | Renesas Electronics Corporation | Renesas Electronics Corporation | Renesas Electronics Corporation | Renesas Electronics Corporation |
| RoHS Status | ROHS3 Compliant | Not applicable | Not applicable | ROHS3 Compliant |
| Description | P-CHANNEL POWER MOSFET | P-CHANNEL POWER MOSFET | P-CHANNEL POWER MOSFET | 4.4A, 20V, P-CHANNEL MOSFET |
| Series | * | * | * | - |
| Packaging | Bulk | Bulk | Bulk | Bulk |
