HDSM-283C
lmages are for reference only.HDSM-283C
DISPLAY 7SEG 0.28" SGL RED 12SMD
Datasheet12-SMD, No Lead, 11 Pads
48,124 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Display Modules - LED Character and Numeric Red 7-Segment 1 Character Common Cathode 2V 20mA 0.425" H x 0.295" W x 0.124" D (10.80mm x 7.50mm x 3.15mm) 12-SMD, No Lead, 11 Pads
HDSM-283C
| Category | Optoelectronics - LED Character and Numeric - |
| Manufacturer | Broadcom Limited |
| Series | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT)--> |
| RoHS Status | ROHS3 Compliant |
| Number of Characters | 1 |
| Size / Dimension | 0.425" H x 0.295" W x 0.124" D (10.80mm x 7.50mm x 3.15mm) |
| Digit/Alpha Size | 0.28" (7.00mm) |
| Display Type | 7-Segment |
| Common Pin | Common Cathode |
| Color | Red |
| Voltage - Forward (Vf) (Typ) | 2V |
| Current - Test | 20mA |
| Millicandela Rating | 7.5mcd |
| Wavelength - Peak | 632nm |
| Power Dissipation (Max) | 65mW |
| Package / Case | 12-SMD, No Lead, 11 Pads |
| Base Product Number | HDSM-283 |
| Display Format | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | HDSM-283B | HDSM-283F | HDSM-283H | HDSM-283H-LM000 |
| Manufacturer | Broadcom Limited | Broadcom Limited | Broadcom Limited | Broadcom Limited |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | |
| Description | DISPLAY 7SEG 0.28" SGL BLU 12SMD | DISPLAY 7SEG 0.28" SGL YLW 12SMD | DISPLAY 7SEG 0.28" SGL GRN 12SMD | LED |
| Series | - | - | - | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT)--> | Tape & Reel (TR)-->Cut Tape (CT)--> | Tape & Reel (TR)-->Cut Tape (CT)--> | Bulk |
