HDSP-5537
lmages are for reference only.HDSP-5537
DISP 7SEG 0.56" OV/FL RED 10DIP
Datasheet10-DIP (0.600", 15.24mm), 9 Leads
56,754 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Display Modules - LED Character and Numeric Red 7-Segment +/-1 (overflow) Character Common Anode 2.6V 100mA 0.670" H x 0.495" W x 0.315" D (17.02mm x 12.57mm x 8.00mm) 10-DIP (0.600", 15.24mm), 9 Leads
HDSP-5537
| Category | Optoelectronics - LED Character and Numeric - |
| Manufacturer | Broadcom Limited |
| Series | - |
| Packaging | Bulk |
| RoHS Status | |
| Number of Characters | +/-1 (overflow) |
| Size / Dimension | 0.670" H x 0.495" W x 0.315" D (17.02mm x 12.57mm x 8.00mm) |
| Digit/Alpha Size | 0.56" (14.22mm) |
| Display Type | 7-Segment |
| Common Pin | Common Anode |
| Color | Red |
| Voltage - Forward (Vf) (Typ) | 2.6V |
| Current - Test | 100mA |
| Millicandela Rating | 7mcd |
| Wavelength - Peak | 635nm |
| Power Dissipation (Max) | 105mW |
| Package / Case | 10-DIP (0.600", 15.24mm), 9 Leads |
| Base Product Number | HDSP-553 |
| Display Format | - |
| Product Attribute | |
|
 |
 |
| Part Number | HDSP-501B | HDSP-503B | HDSP-511A | HDSP-511E |
| Manufacturer | Broadcom Limited | Broadcom Limited | Broadcom Limited | Broadcom Limited |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ||
| Description | DISPLAY 7SEG 0.56" SGL BLU 10DIP | DISPLAY 7SEG 0.56" SGL BLU 10DIP | DISPLAY 7SEG 0.56" SGL RED 10DIP | DISPLAY 7SEG 0.56" SGL RED 10DIP |
| Series | - | - | - | - |
| Packaging | Bulk | Bulk | Bulk | Bulk |
