Product CatalogPart Number
HEDS-9140#A00
Manufacturer
Broadcom LimitedDescription
ROTARY ENCODER OPTICAL 500PPR
Datasheet
DatasheetPackage
-
In Stock
22,831 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
HEDS-9140#A00
HEDS-9140#A00
lmages are for reference only.Payment Methods
Delivery Services
Rotary Encoder Optical 500 Quadrature with Index (Incremental) Vertical
Quick Inquiry
HEDS-9140#A00
Specifications
| Category | Sensors, Transducers - Encoders - |
| Manufacturer | Broadcom Limited |
| Series | HEDS |
| Packaging | Bulk |
| RoHS Status | ROHS3 Compliant |
| Encoder Type | Optical |
| Output Type | Quadrature with Index (Incremental) |
| Pulses per Revolution | 500 |
| Voltage - Supply | 5V |
| Actuator Type | Codewheel Not Included |
| Detent | No |
| Built in Switch | No |
| Mounting Type | Chassis Mount |
| Orientation | Vertical |
| Termination Style | Terminal Pins |
| Rotational Life (Cycles Min) | - |
| Base Product Number | HEDS-9140 |
| Grade | - |
| Qualification | - |
