HERF1006G
lmages are for reference only.HERF1006G
DIODE ARRAY GP 600V 10A ITO220AB
DatasheetTO-220-3 Full Pack, Isolated Tab
38,452 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Diode Array 1 Pair Common Cathode 600 V 10A Through Hole TO-220-3 Full Pack, Isolated Tab
HERF1006G
| Category | Discrete Semiconductor Products - Diodes - Rectifiers |
| Manufacturer | Taiwan Semiconductor Corporation |
| Series | - |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| Diode Configuration | 1 Pair Common Cathode |
| Technology | Standard |
| Voltage - DC Reverse (Vr) (Max) | 600 V |
| Current - Average Rectified (Io) (per Diode) | 10A |
| Voltage - Forward (Vf) (Max) @ If | 1.7 V @ 10 A |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) |
| Current - Reverse Leakage @ Vr | 10 µA @ 600 V |
| Operating Temperature - Junction | -55°C ~ 150°C |
| Mounting Type | Through Hole |
| Package / Case | TO-220-3 Full Pack, Isolated Tab |
| Supplier Device Package | ITO-220AB |
| Base Product Number | HERF1006 |
| Reverse Recovery Time (trr) | 80 ns |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | HERF1006GH | HERF1001G | HERF1001G C0G | HERF1001GH |
| Manufacturer | Taiwan Semiconductor Corporation | Taiwan Semiconductor Corporation | Taiwan Semiconductor Corporation | Taiwan Semiconductor Corporation |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ||
| Description | DIODE ARRAY GP 600V 10A ITO220AB | DIODE ARRAY GP 50V 10A ITO220AB | DIODE ARRAY GP 50V 10A ITO220AB | DIODE ARRAY GP 50V 10A ITO220AB |
| Series | - | - | - | - |
| Packaging | Tube | Tube | Tube | Tube |
