HFW1101G01M
lmages are for reference only.HFW1101G01M
RELAY GEN PURPOSE DPDT 2A 12V
Datasheet-
74,222 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
General Purpose Relay DPDT (2 Form C) Through Hole
HFW1101G01M
| Category | Relays - Signal Relays-Up to 2 Amps - |
| Manufacturer | TE Connectivity Aerospace, Defense and Marine |
| Series | HFW, CII |
| Packaging | Bulk |
| RoHS Status | RoHS non-compliant |
| Mounting Type | Through Hole |
| Coil Voltage | 12VDC |
| Contact Form | DPDT (2 Form C) |
| Contact Rating (Current) | 2 A |
| Switching Voltage | - |
| Load - Max Switching | - |
| Coil Type | Non Latching |
| Features | - |
| Termination Style | Solder Hook |
| Seal Rating | Sealed - Hermetically |
| Coil Insulation | - |
| Must Operate Voltage | 6.4 VDC |
| Must Release Voltage | 0.7 VDC |
| Operate Time | 4 ms |
| Release Time | 4 ms |
| Operating Temperature | -65°C ~ 125°C |
| Contact Material | Silver (Ag), Gold (Au) |
| Approval Agency | - |
| Relay Type | General Purpose |
| Grade | - |
| Qualification | - |
| Base Product Number | 1617028 |
| Coil Current | 75 mA |
| Coil Resistance | 160 Ohms |
| Product Attribute | |
|
|
|
| Part Number | HFW1101K00 | HFW1101K06 | HFW1101K07M | HFW1101K12 |
| Manufacturer | TE Connectivity Aerospace, Defense and Marine | TE Connectivity Aerospace, Defense and Marine | TE Connectivity Aerospace, Defense and Marine | TE Connectivity |
| RoHS Status | RoHS non-compliant | RoHS non-compliant | RoHS non-compliant | RoHS non-compliant |
| Description | RELAY GEN PURPOSE DPDT 2A 26.5V | RELAY GEN PURPOSE DPDT 2A 26.5V | RELAY GEN PURPOSE DPDT 2A 26.5V | Low Signal Relays - PCB HFW 1/2 |
| Series | HFW, CII | HFW, CII | HFW, CII | * |
| Packaging | Bulk | Bulk | Bulk | Tray |
