HFW1V2815H220K
lmages are for reference only.HFW1V2815H220K
IND HC 22UH 8.6A SMD
Datasheet3-SMD, Gull Wing
69,556 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
22 µH Unshielded Wirewound Inductor 30 A 2.05mOhm Max 3-SMD, Gull Wing
HFW1V2815H220K
| Category | Inductors, Coils, Chokes - Fixed Inductors - |
| Manufacturer | Eaton - Electronics Division |
| Series | HFW1V28xxH |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| Type | Wirewound |
| Material - Core | Ferrite |
| Inductance | 22 µH |
| Tolerance | ±10% |
| Current Rating (Amps) | 30 A |
| Current - Saturation (Isat) | 8.6A |
| Shielding | Unshielded |
| DC Resistance (DCR) | 2.05mOhm Max |
| Q @ Freq | - |
| Frequency - Self Resonant | 8.8MHz |
| Ratings | - |
| Operating Temperature | -40°C ~ 125°C |
| Inductance Frequency - Test | 500 kHz |
| Features | - |
| Mounting Type | Surface Mount |
| Package / Case | 3-SMD, Gull Wing |
| Supplier Device Package | 3-SMD |
| Size / Dimension | 1.098" L x 0.780" W (27.90mm x 19.80mm) |
| Height - Seated (Max) | 0.605" (15.36mm) |
| Base Product Number | - |
| Product Attribute | |
 |
|
 |
| Part Number | HFW1V2815H220K | HFW1V2815H2R2K | HFW1V2815H100K | HFW1V2815H150K |
| Manufacturer | Eaton - Electronics Division | Eaton - Electronics Division | Eaton - Electronics Division | Eaton - Electronics Division |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | IND HC 22UH 8.6A SMD | IND HC 2.2UH 100A SMD | IND HC 10UH 21.5A SMD | IND HC 15UH 14A SMD |
| Series | Eaton - Electronics Division | Eaton - Electronics Division | Eaton - Electronics Division | Eaton - Electronics Division |
| Packaging | Tape & Reel (TR) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR) | Tape & Reel (TR)-->Cut Tape (CT) |
