HFW22S-4STZE1HLF
Manufacturer
Amphenol ICC (FCI)Description
CONN FFC FPC VERT 22POS 1MM SMD
Datasheet
DatasheetPackage
-
In Stock
97,833 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
HFW22S-4STZE1HLF
HFW22S-4STZE1HLF
lmages are for reference only.Payment Methods
Delivery Services
22 Position FFC, FPC Connector Contacts, Vertical - 1 Sided 0.039" (1.00mm) Surface Mount
Quick Inquiry
HFW22S-4STZE1HLF
Specifications
| Category | Connectors, Interconnects - FFC-FPC Flat Flexible Connectors - FFC-FPC Flat Flexible Connector Assemblies |
| Manufacturer | Amphenol ICC (FCI) |
| Series | HFW-S |
| Packaging | Tape & Reel (TR) |
| RoHS Status | |
| Flat Flex Type | FFC, FPC |
| Mounting Type | Surface Mount |
| Connector/Contact Type | Contacts, Vertical - 1 Sided |
| Number of Positions | 22 |
| Pitch | 0.039" (1.00mm) |
| Termination | Solder |
| FFC, FCB Thickness | 0.30mm, 0.33mm |
| Height Above Board | 0.209" (5.30mm) |
| Locking Feature | - |
| Cable End Type | Straight, Tapered |
| Contact Material | Phosphor Bronze |
| Contact Finish | Tin |
| Housing Material | Liquid Crystal Polymer (LCP), Glass Filled, Halogen Free |
| Actuator Material | - |
| Features | - |
| Voltage Rating | 100V |
| Operating Temperature | - |
| Material Flammability Rating | UL94 V-0 |
| Current Rating (Amps) | 1A |
| Contact Finish Thickness | - |
| Housing Color | Black |
| Actuator Color | - |
| Mating Cycles | - |
| Base Product Number | HFW22S |
