HLE-115-02-SM-DV-BE-A
Manufacturer
Samtec Inc.Description
CONN RCPT 30POS 0.1 GOLD SMD
Datasheet
DatasheetPackage
-
In Stock
86,809 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
HLE-115-02-SM-DV-BE-A
HLE-115-02-SM-DV-BE-A
lmages are for reference only.Payment Methods
Delivery Services
30 Position Receptacle, Bottom Entry Connector 0.100" (2.54mm) Surface Mount Gold
Quick Inquiry
HLE-115-02-SM-DV-BE-A
Specifications
| Category | Connectors, Interconnects - Rectangular Connectors - Headers-Receptacles-Female Sockets |
| Manufacturer | Samtec Inc. |
| Series | HLE |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| Connector Type | Receptacle, Bottom Entry |
| Contact Type | Female Socket |
| Style | Board to Board |
| Number of Positions | 30 |
| Number of Positions Loaded | All |
| Pitch - Mating | 0.100" (2.54mm) |
| Number of Rows | 2 |
| Row Spacing - Mating | 0.100" (2.54mm) |
| Mounting Type | Surface Mount |
| Termination | Solder |
| Fastening Type | Push-Pull |
| Contact Finish - Mating | Gold |
| Contact Finish Thickness - Mating | 30.0µin (0.76µm) |
| Insulation Color | Black |
| Insulation Height | 0.144" (3.66mm) |
| Contact Length - Post | - |
| Operating Temperature | -55°C ~ 125°C |
| Material Flammability Rating | - |
| Contact Finish - Post | Tin |
| Mated Stacking Heights | - |
| Ingress Protection | - |
| Features | Board Guide |
| Current Rating (Amps) | 4.1A per Contact |
| Voltage Rating | 400VAC |
| Applications | - |
| Insulation Material | Liquid Crystal Polymer (LCP) |
| Contact Shape | Square |
| Contact Material | Beryllium Copper |
| Contact Finish Thickness - Post | - |
| Base Product Number | HLE-115 |
