RF Amplifier IC 14GHz ~ 27GHz 24-QFN (4x4)
HMC504LC4BTR-R5
| Category | RF and Wireless - RF Amplifiers - |
| Manufacturer | Analog Devices Inc. |
| Series | - |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| Frequency | 14GHz ~ 27GHz |
| P1dB | 17dBm |
| Gain | 19dB |
| Noise Figure | 4.5dB |
| RF Type | - |
| Voltage - Supply | 4V |
| Current - Supply | 90mA |
| Test Frequency | 14GHz ~ 27GHz |
| Mounting Type | Surface Mount |
| Package / Case | 24-TFQFN Exposed Pad |
| Supplier Device Package | 24-QFN (4x4) |
| Base Product Number | HMC504 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | HMC504LC4B | HMC504LC4BTR | HMC505LP4 | HMC505LP4E |
| Manufacturer | Analog Devices Inc. | Analog Devices Inc. | Analog Devices Inc. | Analog Devices Inc. |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | IC RF AMP GPS 14GHZ-27GHZ 24CLCC | IC RF AMP GPS 14GHZ-27GHZ 24QFN | IC AMP VSAT 6.8GHZ-7.4GHZ 24QFN | IC AMP VSAT 6.8GHZ-7.4GHZ 24QFN |
| Series | - | - | - | - |
| Packaging | Strip | Tape & Reel (TR)-->Cut Tape (CT) | Strip | Strip |
