HMC755LP4E
lmages are for reference only.HMC755LP4E
IC AMP LTE 2.3GHZ-2.8GHZ 24QFN
Datasheet24-VFQFN Exposed Pad
29,133 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
RF Amplifier IC LTE, WiMax 2.3GHz ~ 2.8GHz 24-QFN (4x4)
HMC755LP4E
| Category | RF and Wireless - RF Amplifiers - |
| Manufacturer | Analog Devices Inc. |
| Series | - |
| Packaging | Strip |
| RoHS Status | |
| Frequency | 2.3GHz ~ 2.8GHz |
| P1dB | 31dBm |
| Gain | 31dB |
| Noise Figure | - |
| RF Type | LTE, WiMax |
| Voltage - Supply | 5V |
| Current - Supply | 480mA |
| Test Frequency | - |
| Mounting Type | Surface Mount |
| Package / Case | 24-VFQFN Exposed Pad |
| Supplier Device Package | 24-QFN (4x4) |
| Base Product Number | HMC755 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |  |  |  |
| Part Number | HMC755LP4ETR | HMC707LP5E | HMC708LP5E | HMC715LP3E |
| Manufacturer | Analog Devices Inc. | Analog Devices Inc. | Analog Devices Inc. | Analog Devices Inc. |
| RoHS Status | ||||
| Description | IC AMP LTE 2.3GHZ-2.8GHZ 24QFN | IC AMP WIMAX 700MHZ-1.2GHZ 32QFN | IC AMP WIMAX 1.7GHZ-2.2GHZ 32QFN | IC AMP LTE 2.1GHZ-2.9GHZ 16QFN |
| Series | - | - | - | - |
| Packaging | Tape & Reel (TR) | Strip | Strip | Strip |
