Product CatalogPart Number
HSEC8-109-01-L-DV-A-BL-K
Manufacturer
Samtec Inc.Description
CONN EDGE DUAL FMALE 18POS 0.031
Datasheet
DatasheetPackage
-
In Stock
20,343 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
HSEC8-109-01-L-DV-A-BL-K
HSEC8-109-01-L-DV-A-BL-K
lmages are for reference only.Payment Methods
Delivery Services
18 Position Female Connector Non Specified - Dual Edge Gold 0.031" (0.80mm) Black
Quick Inquiry
HSEC8-109-01-L-DV-A-BL-K
Specifications
| Category | Connectors, Interconnects - Card Edge Connectors - Edgeboard Connectors |
| Manufacturer | Samtec Inc. |
| Series | |
| Packaging | Tray |
| RoHS Status | ROHS3 Compliant |
| Series | Edge Rate™ HSEC8 |
| Card Type | Non Specified - Dual Edge |
| Gender | Female |
| Number of Positions/Bay/Row | 9 |
| Number of Positions | 18 |
| Card Thickness | 0.062" (1.57mm) |
| Number of Rows | 2 |
| Pitch | 0.031" (0.80mm) |
| Read Out | Dual |
| Features | Board Guide, Board Lock |
| Mounting Type | Surface Mount |
| Termination | Solder |
| Contact Material | Beryllium Copper |
| Contact Finish | Gold |
| Contact Finish Thickness | 10.0µin (0.25µm) |
| Contact Type | Cantilever |
| Color | Black |
| Flange Feature | - |
| Operating Temperature | -55°C ~ 125°C |
| Material - Insulation | Liquid Crystal Polymer (LCP) |
| Base Product Number | HSEC8-109 |
| Termination Rows | - |
