IAUC100N10S5L054ATMA1
lmages are for reference only.IAUC100N10S5L054ATMA1
MOSFET_(75V 120V( PG-TDSON-8
Datasheet8-PowerTDFN
25,942 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
N-Channel 100 V 101A (Tj) 130W (Tc) Surface Mount PG-TDSON-8-34
IAUC100N10S5L054ATMA1
| Category | Discrete Semiconductor Products - Transistors - FETs-MOSFETs |
| Manufacturer | Infineon Technologies |
| Series | OptiMOS™ |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| FET Type | N-Channel |
| Technology | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 100 V |
| Current - Continuous Drain (Id) @ 25°C | 101A (Tj) |
| Drive Voltage (Max Rds On, Min Rds On) | 4.5V, 10V |
| Rds On (Max) @ Id, Vgs | 5.4mOhm @ 50A, 10V |
| Vgs(th) (Max) @ Id | 2.2V @ 64µA |
| Vgs (Max) | ±20V |
| Input Capacitance (Ciss) (Max) @ Vds | 3744 pF @ 50 V |
| FET Feature | - |
| Power Dissipation (Max) | 130W (Tc) |
| Operating Temperature | -55°C ~ 175°C (TJ) |
| Mounting Type | Surface Mount |
| Supplier Device Package | PG-TDSON-8-34 |
| Package / Case | 8-PowerTDFN |
| Base Product Number | - |
| Gate Charge (Qg) (Max) @ Vgs | 53 nC @ 10 V |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
|
|
 |
| Part Number | IAUC100N10S5L040ATMA1 | IAUC100N10S5N040ATMA1 | IAUC100N04S6L014ATMA1 | IAUC100N04S6L020ATMA1 |
| Manufacturer | Infineon Technologies | Infineon Technologies | Infineon Technologies | Infineon Technologies |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | MOSFET N-CH 100V 100A 8TDSON-34 | MOSFET N-CH 100V 100A 8TDSON-34 | IAUC100N04S6L014ATMA1 | IAUC100N04S6L020ATMA1 |
| Series | OptiMOS™ 5 | OptiMOS™ 5 | OptiMOS™ | OptiMOS™ |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
