Product CatalogPart Number
IF1209S
Manufacturer
XP PowerDescription
DC DC CONVERTER 9V 1W
Datasheet
DatasheetPackage
7-SIP Module, 6 Leads
In Stock
60,104 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
IF1209S
IF1209S
lmages are for reference only.Payment Methods
Delivery Services
Isolated Module DC DC Converter 1 Output 9V 111mA 10.8V - 13.2V Input
Quick Inquiry
IF1209S
Specifications
| Category | Power Supplies - Board Mount - DC DC Converters - |
| Manufacturer | XP Power |
| Series | IF (1W) |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| Type | Isolated Module |
| Number of Outputs | 1 |
| Voltage - Input (Min) | 10.8V |
| Voltage - Input (Max) | 13.2V |
| Voltage - Output 1 | 9V |
| Voltage - Output 2 | - |
| Voltage - Output 3 | - |
| Voltage - Output 4 | - |
| Current - Output (Max) | 111mA |
| Power (Watts) | 1 W |
| Applications | ITE (Commercial) |
| Features | - |
| Operating Temperature | -40°C ~ 85°C |
| Efficiency | 66% |
| Grade | - |
| Qualification | - |
| Mounting Type | Through Hole |
| Package / Case | 7-SIP Module, 6 Leads |
| Size / Dimension | 0.77" L x 0.28" W x 0.50" H (19.5mm x 7.2mm x 12.6mm) |
| Supplier Device Package | - |
| Control Features | - |
| Approval Agency | - |
| Standard Number | - |
| Base Product Number | IF1209 |
| Voltage - Isolation | 1 kV |
Parts with Similar Specifications
| Product Attribute |  |
 |
 |
 |
| Part Number | IF1209S-1WR3 | IF1203S | IF1205S | IF1205S-1WR3 |
| Manufacturer | Mornsun America, LLC | XP Power | XP Power | Mornsun America, LLC |
| RoHS Status | RoHS Compliant | ROHS3 Compliant | ROHS3 Compliant | RoHS Compliant |
| Description | DC-DC ISOLATED 1 W 11.4~12.6V | DC DC CONVERTER 3.3V 1W | DC DC CONVERTER 5V 1W | DC-DC ISOLATED 1 W 11.4~12.6V |
| Series | XP Power | XP Power | ||
| Packaging | IF S-1WR3 | Tube | Tube | IF_S-1WR3 |
