IGBT Trench Field Stop 1350 V 80 A 394 W Through Hole PG-TO247-3
IHW40N135R5XKSA1
| Category | Discrete Semiconductor Products - Transistors - IGBTs |
| Manufacturer | Infineon Technologies |
| Series | TrenchStop™ |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| IGBT Type | Trench Field Stop |
| Voltage - Collector Emitter Breakdown (Max) | 1350 V |
| Current - Collector (Ic) (Max) | 80 A |
| Current - Collector Pulsed (Icm) | 120 A |
| Vce(on) (Max) @ Vge, Ic | 1.95V @ 15V, 40A |
| Power - Max | 394 W |
| Switching Energy | 2mJ (off) |
| Input Type | Standard |
| Gate Charge | 305 nC |
| Td (on/off) @ 25°C | -/410ns |
| Test Condition | 600V, 40A, 10Ohm, 15V |
| Operating Temperature | -40°C ~ 175°C (TJ) |
| Grade | - |
| Qualification | - |
| Mounting Type | Through Hole |
| Package / Case | TO-247-3 |
| Supplier Device Package | PG-TO247-3 |
| Reverse Recovery Time (trr) | - |
| Base Product Number | IHW40N135 |
| Product Attribute |  |
 |
 |
 |
| Part Number | IHW40N135R3FKSA1 | IHW40N120R3FKSA1 | IHW40N120R5XKSA1 | IHW40N140R5LXKSA1 |
| Manufacturer | Infineon Technologies | Infineon Technologies | Infineon Technologies | Infineon Technologies |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ||
| Description | IGBT 1350V 80A 429W TO247-3 | IGBT 1200V 80A 429W TO247-3 | IGBT TRENCH FS 1200V 80A TO247-3 | IGBT 1400V 80A TO247-44 |
| Series | - | TrenchStop® | TrenchStop™ | - |
| Packaging | Tube | Tube | Tube | Tube |
